GSE16GAAE3-F5V5C0 | GSTO eMMC5.1 16GB HS400 Flash
GSE16GAAE3-F5V5C0 – GSTO eMMC5.1 16 GB HS400 flash (310 MB/s read, 200 MB/s write, LDPC ECC, wear leveling, –25 °C to +85 °C operation)
Key Features
- Compliant with JEDEC e.MMC 5.1, backward-compatible with v4.5–v5.1
- HS400 interface: up to 310 MB/s read, 200 MB/s write
- Random IOPS: up to 3,600 read / 2,500 write
- Bus widths supported: 1-, 4-, 8-bit SDR & DDR at 200 MHz
- On-die LDPC ECC, wear leveling, and bad-block management
- Dual boot partitions (4 MB each) and Replay Protected Memory Block (RPMB)
- Secure erase, sanitize, trim, and discard supported
- Supply voltages: VCC 2.7–3.6 V, VCCQ 1.7–1.95 V or 2.7–3.6 V
- Operating temperature: –25 °C to +85 °C
Technical Specifications
| Specification | Details |
|---|---|
| Capacity | 16 GB |
| Interface | e.MMC 5.1 HS400, SDR/DDR up to 200 MHz |
| Max Sequential Read / Write | 310 MB/s / 200 MB/s |
| Random IOPS (Read / Write) | 3,600 / 2,500 |
| Package | 153-ball FBGA, 11.5 × 13 × 1.0 mm |
| Supply Voltages | VCC 2.7–3.6 V; VCCQ 1.7–1.95 V or 2.7–3.6 V |
| Active Current (Read / Write) | 85 mA / 80 mA |
| Standby Current (Auto-Sleep) | 10 µA (VCC) / 75 µA (VCCQ) |
| Sleep Current | 0 µA (VCC off) / 75 µA (VCCQ) |
| Operating Temperature | –25 °C … +85 °C |
| Pre-Burned Capacity | 4.85 GB |
| Boot Partitions | 2 × 4 MB |
| User Data Area | 14,912 MB |
Benefits
- Simplified integration: Embedded flash controller reduces host CPU load
- Reliable performance: Industrial-grade ECC and dynamic wear leveling
- Enhanced security: Boot partitioning, RPMB, secure erase and password protection
- Low power design: Auto-sleep and sleep mode for optimized standby power
- Space-efficient: Ultra-thin BGA package—only 1.0 mm thick
Why Choose GSTO?
GSTO’s GSE16GAAE3-F5V5C0 is engineered for compact, high-speed embedded designs in mobile, consumer and smart devices. With robust firmware and industrial-grade control, it delivers consistent performance and durability across its lifecycle.
Smartphone
Automotive
AI & IoT Devices
Networking Equipment
Industrial PC
Embedded Systems
Smart TV / Media Player
Server / Memory Module
Consumer Electronics
Storage Devices
